Quad ESL 2812 Electrostatic Panel Speakers

ESL 2812 is the first model in the ESL Series. Quad's patented panel technology results in a combination of the speed and accuracy only possible from an electrostatic loudspeaker; together with the imaging and sound-staging only possible from a theoretically ideal point source; and the coherence and continuity of a single drive unit.

With possibly the lowest distortion of any loudspeaker, the ESL can be enjoyed for hours on end without fatigue; never adding or subtracting from the original recording. Even at low volume levels, they retain the full detail and drama of the music.

  • Overload safety
  • Electrostatic Panels
  • Very low distortion elements
  • Crossover free sound reproduction
 Format   Floor Standing Dipole With 3° Fixed Tilt
  Type   Multiple electrostatic drive membranes
  Time Delay   Progressive Concentric Rings
  Chassis Structure   Heavy Duty Composite Aluminium / Steel
  Panel Elements   4
  Maximum Output   2 N/m2 at 2m On Axis
  Sensitivity   1.5 mbar Per Volt Referred To 1m
  (86dB/2.83V rms Equivalent)
 Nominal Impedance   8 Ohms
 Impedance Variation   4 - 15 Ohms

  Maximun Input
  Continuous Input Voltage (rms): 10V
  Programme Peak For Undistorted Output: 40V
  Permitted Peak Input:55V
  Frequency Response   37Hz - 21kHz (-6dB)
  33Hz - 23kHz (useable)
  Directivity Index   See Polar Diagrams

  Distortion (100dB @ 1m)
  Above 1000Hz      <0.15%
  Above 100Hz        <0.5%
  Above 50Hz          <1.0%
  AC Input   220 - 240V, 110 -120V, 100V
  Power Fuse   63mA anti-surge, 200 -240V
  100mA anti-surge, 100 - 120V
  Power Consumption   6W
  Dimensions (H x W x D)   1070 x 690 x 380 (mm)
  Net Weight   35kg
