THERE IS LIFE ABOVE 20KHZ...
and that is why we designed our own ultrasonic generator, a 4mm thin aluminium ribbon driven by a large neodymium magnet and capable of reaching ultrasonic frequencies up to 100kHz. With its great off-axis dispersion and accuracy in producing the leading edge of each transient, the supertweeter makes the whole system sound more natural, giving the reproduced sound a truly three-dimensional quality.
TECHNICAL SPECIFICATIONS
Type
2-way rear-ported stand mounted
Sensitivity
87 dBspl (2.83V, 1m)
Nominal impedance
8Ω (minimum 5Ω)
Drive units
1 x ribbon diaphragm ultrasonic generator
1 x ø 28mm (1.1 in) silk dome neodymium tweeter
1 x ø 165mm (6.5 in) Nomex diaphragm woofer
Frequency response (±3dB)
45 Hz – 100 kHz (typical in-room bass resp. -6dB @39Hz)
Crossover frequencies
2.2 kHz – 30kHz
Recommended amplifier power
50W – 150W into 8Ω with unclipped sound signal
Cabinet
multi-layer composite construction comprised of aluminium panels,solid HDF fiberboard and rubber damping elements
3 different internal absorbent materials
Dimensions
Height: 106.5mm (36.4 in) incl. dedicated stand
Width: 259mm (9.3 in)
Depth: 315mm (11.4in)
Net weight
20 Kg (44 lb) each
32 Kg (70.5 lb) including stand
Cabinet finish
black matt coated aluminium front baffle
exclusive RF silky matt black coating
Side panels
High gloss black
natural walnut
custom leather covering
