empowered by technology
As our flagship cartridges, Donatello's diamond tip is mechanically inserted and blocked into a long, stiffened aluminium cantilever, handled in a special titanium telescopic seat to increase structural rigidity.
Like GN top class models, Donatello features long gold-plated pin connectors designed to connect perfectly with arm cinches, reducing energy dispersion and improving grounding for an ideal music background that will let you enjoy even the smaller details of your music.
Donatello Red features high internal impedance & gain levels, so that it can be easily matched with MM phono preamp while the Donatello Gold can be driven correctly by MC preamps, without the need of any Step-Up transformers.
* all Donatello cartridges come with serial number indelibly printed in the engraved area at the top of the body
technical SPECIFICATIONS
Typology: MC low Output Phono Cartridge
Output level: 0.5mV
Frequency response: 10-40000Hz
Impedance: 40Ω
Suggested load: 470Ω
Compliance: 12×10-6cm/dyne
Channel separation: > 25dB
Channel balance: < 1db
Suggested tracking weight: 1.8 to 2.1g
Cantilever: Aluminum
Diamond: Micro Elliptical
Coil Wire: Copper
Magnet: Samarium-Cobalt
Mounting hole diamond distance: 9mm
Finishes
BODY
Duraluminium alloy
COLOR
Gold with Black Logo
