Input USB3.0 B Socket (USB2.0 compatible)
Formats
44.1/48/88.2/96/176.4/192kHz PCM
2.8/3.1/5.6/6.2/11.2/12.4MHz DSD
352.8/384KHz DXD
MQA
DAC Bit-Perfect DSD & DXD DAC by Burr Brown
OUTPUTS
Balanced
4.4 mm
2V-6.2V max.
(variable)/4.2V (fixed)
RCA (SE) 1V-3.3V max.
(variable)/2.1V (fixed)
ZOUT
Balanced <= 200 Ohm
SE <= 100 Ohm
SNR <-117 dB(A) @ 0dBFS (BAL/SE)
DNR >117 dB(A) @ -60dBFS (BAL/SE)
THD+N <0.0011% @ 0dBFS (BAL/SE)
Power consumption 5V / 174ma, P = 0.887W (on idle using included iPower)
Dimensions
117 (L) x 100 (W) x 30 (H) mm
4.6‘’(L) x 3.9”(W) x 1.2’’(H)
Weight 0.75kg / 1.65lbs
