Monitor Audio WSS130 Creator Series In-Wall Speaker
Zoom  Zoom
Monitor Audio WSS130 Creator Series In-Wall SpeakerMonitor Audio WSS130 Creator Series In-Wall SpeakerMonitor Audio WSS130 Creator Series In-Wall Speaker

Monitor Audio WSS130 Creator Series In-Wall Speaker

Available In-Store Only or Buy and Collect

£265.00
£220.83 Exc. VAT |  |

Monitor Audio WSS130 Creator Series In-Wall Speaker

The WSS line offers a refreshingly simple ‘good, better, best’ menu. The Super Slim WSS speakers offer unique flexibility, performance, and elegant aesthetics to achieve perfect results for the most technical demanding applications.

The WSS130 is the entry-point, and is ideal for general home theatre and music applications. Featuring three bass/mid-range drivers plus one tweeter, the speakers have been smartly designed to enable the performance of a significantly larger monitor. The three-driver layout is key here, as it helps keep the frontal profile look slender, as well as deliver a depth of a mere 50 mm. The WSS130 features MMP II cone drivers, augmented by a 25 mm Gold Dome tweeter. This MMP cone technology allows for a simple crossover design and smooth overall sound character.

The WSS130 includes Monitor Audio’s patented ‘tri-grip’ mounting system meaning you get a robust fixing. This system has been proven over the last decade in the CT and WT ranges, so you know it works brilliantly. All three models share the same footprint and pre-construction bracket, providing simplicity as well as the option of specifying a higher performance model in the range before completion.


Key Features

  • Good, better, best performance levels
  • Super-Slim depth 50 mm (2") – designed to fit in 2" stud walls or where space is restricted
  • Designed for portrait or landscape installation – fits between standard 14" stud bays
  • Elegant, slim profile only 385 x 140 mm wide
  • Three, 3" bass/mid-range drivers featuring incremental technology and performance benefits – MMP II, C-CAM and dished C-CAM cones
  • 25 mm C-CAM Gold Dome tweeter used on WSS130 and WSS230 models. WSS430 utilises MPD high frequency transducer from Platinum IC model and flagship Platinum II speaker range
  • High quality crossover components – Selected and voiced for amazing sonic performance
  • Magnetically attached ‘trim-less’ grille – discreet, reliable, and easy servicing
  • Tri-Grip Dog leg fixings – reliable, robust, and quick to install
  • Gold plated sprung push terminals – easy to connect and reliable
  • Paintable grille – to complement and blend with décor
  • WSS430 has rotating tweeter for optimum dispersion when used in landscape configuration
  • WB3 (dark blue) pre-construction bracket

Frequency Response (-6 dB)

75 Hz – 30 kHz

Sensitivity (1W@1M)

87 dB

Nominal Impedance

8 ohms

Maximum SPL

105.6 dBA

Power Handling (RMS)

60 W – Full range (100 W with crossover set to 100 Hz @ 12 dB/Octave)

Recommended Amplifier Requirements

10 – 100 W

Drive Unit Complement

3 x 3" MMP II cone bass-mid drivers
1 x 25 mm (1") C-CAM Gold Dome tweeter

Crossover Recommendation using AVR/Processor

100 Hz at a minimum of 12 dB/Octave (24 dB/Octave optimum)

Overall Dimensions

385 x 140.5 mm (15 x 51/2")

Overall Depth (Including Grille)

54.25 mm (21/8")

Cut-Out Dimensions

346 x 101 mm (131/2 x 4")

Mounting Depth

50 mm (2")

Connection

Gold Plated Sprung push terminals – For bare wire connection up to 3 mm2

Fixing Type

6 position Tri-Grip dog leg fixings

Construction Material

Mineral filled ABS Plastic, RoHS2 Compliant. Painted steel grille

Weight

1.4 kg (3 lb 2 oz)

Sold As

Single Unit
